OBD 2 Pinout Explained

On-Board Diagnostics II, or OBD2, is a self-diagnostic and reporting system in modern vehicles. It consists of an Electronic Control Unit, several sensors, and indicator lights. The sensors inspect the various subsystems within the vehicle and report any faults and abnormalities to the ECU.

Of course, simply reporting faults would be pointless if there was no way to read the errors and act on them. Hence, the ECU generates Diagnostic Trouble Codes and stores them for inspection by external OBD scanners . These codes are accessed through an OBD2 connector plugged into the 16-pin OBD port.

Consequently, repair technicians can analyze the error codes using a scan tool attached to the other end of the connector.

Are you confused by the various terminology thrown about? Read on to learn what an OBD2 connector is and its purpose in your vehicle.

What is the OBD2 Connector for?

The OBD2 connector is one end of the adapter cable plugged into your vehicle’s OBD port . It is a communication interface that allows you to transmit information between a diagnostic scan tool and the vehicle’s OBD2 system.

OBD2 connectors come in two flavors; wired and wireless. As the name suggests, the wired connector must be physically attached to the scan tool through the cable. On the other hand, wireless OBD2 connectors interface with the scan tool using Bluetooth or WiFi.

The OBD2 connector is designed to read and translate real-time diagnostic information from the Electronic Control Unit (ECU). As such, you can tell what is wrong with the vehicles from the error codes received through the connector. Furthermore, it allows you to use scan tools to reprogram and repair the various subsystems within the vehicle. Recently, remote diagnostic systems have become increasingly popular.

OBD2 Port Pinout Types

There are two major types of OBD2 connectors. Type A connectors have a 12V output voltage and are commonly found in small vehicles such as cars. However, type B connectors are usually found in medium-sized and heavy vehicles. Moreover, they have an output power supply of 24V.

Baud rate is the rate of information transfer in serial communication channels. A rate of 24,000 bauds means the port can transfer up to 24,000 bits per second. Type A connectors have an approximate baud rate of 500,000 bauds, while type B connectors have a maximum baud rate of 250,000.

The higher the baud rate, the shorter the length of the adapter cable. As such, it is not uncommon to find type B connectors with longer cables than type A connectors. Nevertheless, you should note that this is not a reliable method of distinguishing between the two cable types.

OBD2 Pinout Explanation

OBD2 connectors are typically 16-pin ports, each pin serving a distinct purpose. Some pins use standard protocols defined by the Society of Automotive Engineers and the International Organization for Standardization. Other pins are left to the manufacturer’s discretion.

The table below gives a quick overview of each pin in a generic OBD2 connector.

Each of these pins is explained in-depth below.

SAE J1850 PWM (Pulse Width Modulation)

• Bus positive pin (2) and bus negative pin (10) of the protocol.
• It uses variable pulse width modulation at 41.6 kb/s.
• It is common in Ford vehicles.
• Pulse Width Modulation changes the analog signal to digital in a square wave.

Controller Area Network (CAN)

• It is a network of independent controllers.
• It is headless; no host computer.
• It uses a bus communication protocol.

SAE J1850 VPW

• Commonly used in General Motors vehicles
• It operates variable pulse width at 10.4 kb/s.
• Pins 2, 4, 5, and 16 have SAE J1850 VPW.
• General Motors developed the Variable Pulse Width encoding method.
• VPW is better than the PWM scheme.
• It is an old protocol
• Mostly used in European vehicles, some Asian vehicles, and Chrysler.
• It uses asynchronous serial communication at 0.4 kb/s.
• It is optional on pins 7 and 15 (pins 4, 5, and 16 are must-haves).
• This protocol represents voltage logic in 0 or 1 form. Logic 0 represents low voltage and Logic 1 represents high voltage. Each bit of information is 96 us long.

ISO 14230 KWP2000

• It operates at 10.4 kb/s and is used for serial asynchronous communication.
• This protocol is most common in Europe and Chrysler vehicles.
• This protocol is used in Asian vehicles having pin 7 K-line.
• It is optional in pin 15.
• KWP is Keyword Protocol. It is a communication protocol that is applied to the OBD system.

ISO 15765-4 CAN (SAE J2480)

• ISO 15765-4 CAN is available in vehicles built in 2008 or later in the US.
• Pins 4, 5, 6, 14, and 16 support this protocol.
• OBD2 protocol consists of 4 variants.
• It works on a 2-wire communication method.
• It can handle up to 1 Mbps.

Main Car Manufacturers OBD2 Connector Pinouts

OBD2 ports are standardized to work with any commercially available scan tool. However, several pins, including 1, 3, 8, and 9 are not required for standard communication. As a result, vehicle manufacturers encode these pins to transmit information specific to each vehicle's make and model.

Furthermore, the standardized pins encode different types of data to be decrypted by the scan tool. Finding specific information about each vehicle manufacturer can be difficult and confusing. Luckily, we have compiled a spreadsheet of the OBD2 pinouts of some popular car manufacturers. Simply click on the name of the brand you're interested in to see its OBD2 pin layout.

Audi OBD2 connector pinout

Acura OBD2 connector pinout

BMW OBD2 connector pinout

Crysler OBD2 connector pinout

Ford OBD2 connector pinout

GM OBD2 connector pinout

Honda OBD2 connector pinout

Hyundai OBD2 connector pinout

Infinity OBD2 connector pinout

KIA OBD2 connector pinout

Lexus OBD2 connector pinout

Mazda OBD2 connector pinout

Mercedes Benz OBD2 connector pinout

Mitsubishi OBD2 connector pinout

Nissan OBD2 connector pinout

Renault OBD2 connector pinout

Subaru OBD2 connector pinout

Toyota OBD2 connector pinout

Volkswagen OBD2 connector pinout

Volvo OBD2 connector pinout

• 4.8 overall rank based on 386 + Reviews
• Requirements: Windows, macOS, Linux, Android and Raspberry Pi.
• 10.45MB Size.
• Version 6.1.15025 . ( 19 Feb, 2024 ).
• Pricing starts $14 per month billed annually
• USB over network
• Remote Vehicle Diagnostics
• OBD2 pinout

OBD2 Connector Pinout, Types & Codes(Explained)

Last updated on March 23rd, 2024 at 11:01 am

OBD2 is an onboard diagnostic system present in cars that collect data from a vehicle. To collect this data, the cars must have an OBD port installed in them. Using an OBD connecter, a technician may collect this data and analyze the errors in the car. But, to see how all of this works, let us first understand what an OBD port and connector is.

Table of Contents

What is an obd2 port.

It is a 16-pin OBD port present in your car that is used by the technician to find faults in the car. The technician connects an OBD2 connector to this port that converts the error data into readable format. This error data is gathered by the OBD2 system installed in the car.

What is an OBD2 connector?

The OBD2 connector is one end of the OBD2 cable that goes to the OBD2 port of the car. The other end of the cable connects to the OBD2 scanner . This way the OBD2 adaptor cable reads the error codes from the OBD2 system and displays them on the scanner.

Sometimes this OBD2 connector comes attached to a Bluetooth scanner. Using this Bluetooth scanner, you can check data wirelessly from a laptop, mobile, etc.

It is used to get real-time data information and onboard diagnostics results. Each manufacturer uses its own OBD-II Diagnostic Link Connector (DLC) which is the main connector through which all subsystems are tuned, reprogrammed & diagnosed.

OBD2 connector pinout

OBD connector has 16 pins in a trapezoidal shape. The following diagram shows the picture of an OBD2 connector pinout.

The table below describes each pin:

What are the types of OBD2 connectors?

There are two types of OBD2 connectors used in a vehicle, i.e., Type A and Type B.

Type A vs. Type B

• Type A is commonly found in cards, while Type B is common in heavy & medium vehicles.
• Both A & B types have similar OBD2 pinouts, but the output power supply is different: 12V for type A and 24V for type B.
• There is a difference in the Baud Rate. The cars use approximately 500K, while most heavy-duty vehicles use 250K.

Now let’s discuss these pins in a bit more detail.

SAE J1850 PWM

• SAE J1850 PWM protocol with connector pins 2 & 10.
• It produces a signal by pulse width modulation. It performs at the speed of 41.6 kb/sec and is mostly found in Ford vehicles.
• Pins 2, 4, 5, 10, and 16 should be of this type.
• PWM stands for Pulse Width Modulation. In PWM, an analog signal is changed into a digital signal in a different wave-like square wave.

SAE J1850 VPW

• For GM vehicles, SAE J1850 VPW is commonly used.
• It operates at a speed of 10.4 kb/sec by the variable pulse width.
• Pins 2, 4, 5, and 16 have SAE J1850 VPM. At pin no. 10 there is a difference between VPW and PWM is that this OBD2 protocol.
• VPM-It was developed by General Motors and it is an encoding method. It stands for Variable Pulse Width and its signal rate is 10.4 Kbps.
• VPM is more beneficial than the PWM scheme.
• Old protocol
• Mostly used in European vehicles. Also in some Asian vehicles & in Chrysler.
• Its running speed is 10.4 kb/sec and it uses serial communication asynchronously.
• It is optional pins 7& 15 (pins 4, 5, and 16 are must-haves).
• ISO stands for International Organization for Standardization. This protocol represents voltage in a logic 0 or 1 form. Logic 0 represents low voltage and logic 1 represents high voltage. In this, each bit of information is 96 us long.

ISO 14230 KWP2000

• It operates at 10.4 kb/s. It is used for serial asynchronous communication.
• This protocol is most common in Europe and commonly in Chrysler. This protocol used in Asian vehicles having pin 7 Kline & pin 15 is optional.
• KWP is Keyword Protocol. It is used for communication protocol which is applied on the OBD system.

ISO 15765-4 CAN (SAE J2480)

• ISO 15765-4 CAN is available in vehicles that were built in 2008 or later in the US.
• Pins 4, 5, 6, 14, and 16 support this protocol.
• OBD2 protocol consists of 4 variants.
• It works on a 2-wire communication method.
• It can handle up to 1 Mbps.

CAN – stands for controller area network

• It refers to a network of independent controllers.
• The communication happens without a host computer.
• It uses a broadcast type of bus communication protocol.

What is an OBD2 code?

Whenever a problem is detected in a vehicle using the OBD, the system shows it as an error code. This code is called a Diagnostic Trouble Code (DTC).

If we try to interpret it, we can understand the cause of the problem. For example , a car shows the P0200 code, which means that there is a possible injector circuit issue. Now, this error can be pinpointed & can be fixed before the actual breakdown.

How to read OBD2 DTC codes?

OBD provides diagnoses for various systems such as powertrain, chassis, body, etc. By careful reading the letters & numbers, a fault can be found & fixed easily. Here the code is simplified as follows:

The first character

It is a letter that denotes the vehicle’s part that has a fault.

P  – Powertrain.

• It includes the vehicle’s engine, transmission, and other associated accessories.

U  – Network & Vehicle Integration

• It is managed by an onboard computer system.
• Parts are usually found in the compartment area of passengers in the vehicle.

C  – Chassis.

• Consists of mechanical functions & systems example, braking, steering, and suspension.

The second character

It is a number that can be ‘0’, ‘1’, ‘2’, or ‘3’.

‘0’, ‘2’, or ‘3’

• standardized (SAE) code or generic code
• Manufacturer specific code

The third character

It is a number or a letter that shows the system in the vehicle that has a fault.

0  – Emission controls: fuel and air metering

1  – Fuel & air metering

2  – Injector circuit: Fuel & air metering

3  – Ignition systems/misfiring

4  – Auxiliary emission control system

5  – Speed Control & idle control systems

6  – Computer and output circuit system

7  – Transmission system

A-F  – Hybrid codes

Final: The fourth and fifth character

It is a two-digit number that defines the exact problem & can be any number between 0 and 99.

Where is the OBD2 port located in a car?

Since OBD port or diagnostic port location varies from manufacturer to manufacturer, it is usually found on the driver’s side under the dashboard. In some vehicles, it can be found near the center console section in a vehicle. In old models, this port can be found near the handbrake or in the trunk.

Once this port is found, we can easily plug the reader which establishes a connection between the vehicle and the diagnostic device.

Best OBD2 connector- our recommendation

2 thoughts on “OBD2 Connector Pinout, Types & Codes(Explained)”

Absolutely great post!

Very straightforward and helpful!

I’m considering buying the obd2 scanner. Your post helped me a lot.

Thanks for sharing.

Can I charge the battery through the OBD connection? ,I think pin 16
